- compatible with ALL34xx/350x/4500/5000 - Measuring range -40...+125 °C, 0...100 %RH - resolution temperature 0,01 °C, resolution humidity: 0.01 % - Measuring accuracy Temp in whole range approx. +/- 0,6° (Typical: -20 + 90° = +/- = 0,2°) - Measuring accuracy humidity in the whole range approx. +/- 3% (Typical: 0~80% +/- 1.5%) - With 1.5 m connection cable Technical Details: Humidity Sensor Specification Parameter Condition Value Units Sensor Humidity Accuracy tolerance1 Typ. ±1.5 %RH Max. -   Repeatability2 Low, typ. 0.21 %RH Medium, typ. 0.15 %RH High, typ. 0.08 %RH Resolution Typ. 0.01 %RH Hysteresis at 25°C ±0.8 %RH Specified range3 extended4 0 to 100 %RH Response time5 t63% 86 s Long-term drift Typ.7 <0.25 %RH/yr       Temperature Sensor Specification   Parameter Condition Value Units ALL3020 Accuracy tolerance1 typ., 20°C to 60°C ±0.1 °C Max. -   Repeatability2 Low, typ. 0.15 °C Medium, typ. 0.08 °C High, typ. 0.04 °C Resolution Typ. 0.01 °C Specified Range - -40 to 125 °C Response time 8 t63% >2 s Long Term Drift max <0.03 °C/yr

Threshold switch for vertical installation (pen with float-ring) made ??of polyamide, resistant to gasoline, oil, brake fluid and much more. 1 m connection cable for ALL3000/ALL4000

Compatible with ALL3000/34xx/3500/400x/4500/5000 Fluid threshold for horizontal installation (hinged float) made ??of polyamide, resistant against gasoline, oil, brake fluid, etc. With 1 m cable

 Highlights:  new compact aluminum desktop- / wallmounting case I2C Bus for multiplexing use either black or white available angle fixings for wall mounting Measure, control and regulate automatically and independently   ALLNET for years been pursuing the concept of intelligent control of processes in building over network and Internet. Intelligent building not only offers comfort, but actively promotes the reduction of energy costs.   Centrally managed and via network / internet accessible the ALLNET Home Automation products allow intelligent building automation regardless of time and location.   The ALL4406 Temperature sensor has a measuring range of -40 to +85 ° C   Temperature sensor in desktop-/ wallmounting case   measuring range of -40 to +85 °C, resolution 0,06 °C Aluminum housing with bracket for wall mounting Multiple multiplexing = multiple modules on one line Interfaces: 2x RJ45 Item Specification Sensor type Temperature and relative humidity Temperature measuring range: -40 to +80 °C  (resolution 0,01 °C) Humidity measuring range: 0...100 % RH (resolution 0,5%) Chip: SHT71 Interfaces: 2x RJ45 (I2C Bus) Multiplexing: pay attention about the same types of sensors on the port! -  see note below LED Indicators: 1x PWR, 1x BUS Housing: metal case Environment: Temperature operating: -45 ~ 90 °C Humidity operating: 0% ~ 100% (non condensed) Temperature storage: -20 ~ 60 °C Humidity storage: 5% ~ 90% (non condensed) Certificates: CE, RoHS Dimension: 79 x 50 x 24 mm (Length x Width x Height) Weight: 230 grams (only device) package content: 1x ALL4418 Temperatore sensor 1x connection cable        Multiplexing - Note to the operation of several sensors on one sensor port   Basically, it is for the ARM and MIPS-based systems possible, unlike to the ALL3000/4000 to operate more than one sensor on a physical port.   Standard hardware requirement is that the sensors are equipped with 2 RJ45 connectors so that the sensor signal can be continued to the next sensor. The total cable length of 100 m does not increase thereby.   So that the sensors can be uniquely identified by the devices, it is necessary that these sensors have different software-I2C chip addresses and IDs. Sensors with the same address and adjustable chip ID can be combined. For sensors without adjustable ID address only one type of sensor can be connected per port.

 Highlights:  new compact aluminum desktop- / wallmounting case I2C Bus for multiplexing use either black or white available angle fixings for wall mounting Measure, control and regulate automatically and independently ALLNET for years been pursuing the concept of intelligent control of processes in building over network and Internet. Intelligent building not only offers comfort, but actively promotes the reduction of energy costs. Centrally managed and via network / internet accessible the ALLNET Home Automation products allow intelligent building automation regardless of time and location. The ALL4406 Temperature sensor has a measuring range of -40 to +85 ° C Temperature sensor in desktop-/ wallmounting case measuring range of -40 to +85 °C, resolution 0,06 °C Aluminum housing with bracket for wall mounting Multiple multiplexing = multiple modules on one line Interfaces: 2x RJ45 Technical Details: Item Specification Sensor type Temperature and relative humidity Temperature measuring range: -40 to +80 °C  (resolution 0,01 °C) Humidity measuring range: 0...100 % RH (resolution 0,5%) Chip: SHT71 Interfaces: 2x RJ45 (I2C Bus) Multiplexing: pay attention about the same types of sensors on the port! -  see note below LED Indicators: 1x PWR, 1x BUS Housing: metal case Environment: Temperature operating: -45 ~ 90 °C Humidity operating: 0% ~ 100% (non condensed) Temperature storage: -20 ~ 60 °C Humidity storage: 5% ~ 90% (non condensed) Certificates: CE, RoHS Dimension: 79 x 50 x 24 mm (Length x Width x Height) Weight: 230 Grams (only device) package content: 1x ALL4418 Temperatore sensor 1x connection cable        Multiplexing - Note to the operation of several sensors on one sensor port   Basically, it is for the ARM and MIPS-based systems possible, unlike to the ALL3000/4000 to operate more than one sensor on a physical port.   Standard hardware requirement is that the sensors are equipped with 2 RJ45 connectors so that the sensor signal can be continued to the next sensor. The total cable length of 100 m does not increase thereby.   So that the sensors can be uniquely identified by the devices, it is necessary that these sensors have different software-I2C chip addresses and IDs. Sensors with the same address and adjustable chip ID can be combined. For sensors without adjustable ID address only one type of sensor can be connected per port.

Highlights: new flat desktop / wall mount case made of aluminium I2C bus for multiplexing use measuring range -40...+125 °C, 0...100 %RH resolution temperature 0,01 °C, resolution humidity: 0.01 % Measuring accuracy Temp in whole range approx. +/- 0.6° (Typical: -20 + 90° = +/- = 0.2°) Measuring accuracy humidity in the whole range approx. +/- 3% (Typical: 0~80% +/- 1,5%) ONLY COMPATIBLE WITH ALL34xx/350x/4500/5000 Angle brackets for wall mounting Measure, control and regulate automatically and independently ALLNET has been pursuing the concept of intelligent control of building technology processes via network and Internet for years. Intelligent building technology not only offers more comfort, but also actively promotes the saving of energy costs. Centrally controlled and accessible via network / Internet, ALLNET building automation products enable intelligent building technology independent of time and location.   Technical Details: Humidity Sensor Specification Parameter Condition Value Units Sensor Humidity Accuracy tolerance1 Typ. ±1.5 %RH Max. -   Repeatability2 Low, typ. 0.21 %RH Medium, typ. 0.15 %RH High, typ. 0.08 %RH Resolution Typ. 0.01 %RH Hysteresis at 25°C ±0.8 %RH Specified range3 extended4 0 to 100 %RH Response time5 t63% 86 s Long-term drift Typ.7 <0.25 %RH/yr       Temperature Sensor Specification   Parameter Condition Value Units ALL3020 Accuracy tolerance1 typ., 20°C to 60°C ±0.1 °C Max. -   Repeatability2 Low, typ. 0.15 °C Medium, typ. 0.08 °C High, typ. 0.04 °C Resolution Typ. 0.01 °C Specified Range - -40 to 125 °C Response time 8 t63% >2 s Long Term Drift max <0.03 °C/yr

• Compatible to ALL3000/34xx/3500/400x/4500/5000 • Contact counter in metal housing • Counts how often a contact has been closed. Max counting frequency: 1000 pulses/second • counter 6-digit decimal (0 … 999999) • 1 m cable

Compatible with ALL3000/34xx/3500/400x/4500/5000 counter in metal case, wall mount option it counts how often the contact has been closed counter frequency: 1000 Impulses/Sec 6-digit counter (0...999999) with 1 m cable

Highlights:   new compact aluminum desktop- / wallmounting case I2C Bus for multiplexing use angle fixings for wall mounting   Measure, control and regulate automatically and independently ALLNET for years been pursuing the concept of intelligent control of processes in building over network and Internet. Intelligent building not only offers comfort, but actively promotes the reduction of energy costs. Centrally managed and via network / internet accessible the ALLNET Home Automation products allow intelligent building automation regardless of time and location. The ALL4429 Combination sensor has a measuring range of 0 to 1023 mbar, -40 to +80 °C and 0...100 % RH Combination Sensor of air pressure/humidity/temperature in desktop-/ wallmounting case measuring range of 0 to 1023 mbar / -40 to +80 °C (resolution 0,01 °C) / 0...100 % RH (resolution 0,5%) Aluminum housing with bracket for wall mounting Multiple multiplexing = multiple modules on one line Interfaces: 2x RJ45 not compactible with ALL3000/ALL5000 Technical Details: Item Specification Sensor type air pressure, humidity, temperature air pressure measuring range: 0 to 1023 mbar Temperature measuring range: -40 to +80 °C  (resolution 0,01 °C) Humidity measuring range: 0...100 % RH (resolution 0,5%) Chip BMP085 + SHT71 Interfaces: 2x RJ45 (I2C Bus) Multiplexing: see note below LED Indicators: 1x PWR, 1x BUS Housing: metal case Environment: Temperature operating: -45 ~ 90 °C Humidity operating: 0% ~ 100% (non condensed) Temperature storage: -20 ~ 60 °C Humidity storage: 5% ~ 90% (non condensed) Certificates: CE, RoHS Dimension: 79 x 50 x 24 mm (Length x Width x Height) Weight: 230 Grams (only device) package content: 1x ALL4429 Combination sensor 1x connection cable     Multiplexing - Note to the operation of several sensors on one sensor port   Basically, it is for the ARM and MIPS-based systems possible, unlike to the ALL3000/4000 to operate more than one sensor on a physical port.   Standard hardware requirement is that the sensors are equipped with 2 RJ45 connectors so that the sensor signal can be continued to the next sensor. The total cable length of 100 m does not increase thereby.   So that the sensors can be uniquely identified by the devices, it is necessary that these sensors have different software-I2C chip addresses and IDs. Sensors with the same address and adjustable chip ID can be combined. For sensors without adjustable ID address only one type of sensor can be connected per port.

Highlights:   new compact aluminum desktop- / wallmounting case I2C Bus for multiplexing use either black or white available angle fixings for wall mounting   Measure, control and regulate automatically and independently   ALLNET for years been pursuing the concept of intelligent control of processes in building over network and Internet. Intelligent building not only offers comfort, but actively promotes the reduction of energy costs.   Centrally managed and via network / internet accessible the ALLNET Home Automation products allow intelligent building automation regardless of time and location.   The ALL4432 Brightness sensor indicates the brightness as value of 0 to 100.   Brightness Sensor in desktop-/ wallmounting case   measuring range of 0 to 100 Aluminum housing with bracket for wall mounting Multiple multiplexing = multiple modules on one line Interfaces: 2x RJ45 (not compatible with ALL3000/400x) Technical Details: Item Specification Sensor type Brightness analog 16bit measuring range: 0 to 100 Chip ADS1100A2 Interfaces: 2x RJ45 (I2C Bus) Multiplexing: pay attention about the same types of sensors on the port! -  see note below LED Indicators: 1x PWR, 1x BUS Housing: metal case Environment: Temperature operating: -45 ~ 90 °C Humidity operating: 0% ~ 100% (non condensed) Temperature storage: -20 ~ 60 °C Humidity storage: 5% ~ 90% (non condensed) Certificates: CE, RoHS Dimension: 79 x 50 x 24 mm (Length x Width x Height) Weight: 230 Grams (only device) package content: 1x ALL4432 Brightness sensor 1x connection cable     Multiplexing - Note to the operation of several sensors on one sensor port   Basically, it is for the ARM and MIPS-based systems possible, unlike to the ALL3000/4000 to operate more than one sensor on a physical port.   Standard hardware requirement is that the sensors are equipped with 2 RJ45 connectors so that the sensor signal can be continued to the next sensor. The total cable length of 100 m does not increase thereby.   So that the sensors can be uniquely identified by the devices, it is necessary that these sensors have different software-I2C chip addresses and IDs. Sensors with the same address and adjustable chip ID can be combined. For sensors without adjustable ID address only one type of sensor can be connected per port.

Highlights: new compact aluminum desktop- / wallmounting case I2C Bus for multiplexing use either black or white available angle fixings for wall mounting Measure, control and regulate automatically and independently ALLNET for years been pursuing the concept of intelligent control of processes in building over network and Internet. Intelligent building not only offers comfort, but actively promotes the reduction of energy costs. Centrally managed and via network / internet accessible the ALLNET Home Automation products allow intelligent building automation regardless of time and location. The ALL4432 Brightness sensor indicates the brightness as value of 0 to 100.   Brightness Sensor in desktop-/ wallmounting case measuring range of 0 to 100 Aluminum housing with bracket for wall mounting Multiple multiplexing = multiple modules on one line Interfaces: 2x RJ45 (not compatible with ALL3000/400x) Technical Details: Item Specification Sensor type Brightness analog 16bit measuring range: 0 to 100 Chip ADS1100A2 Interfaces: 2x RJ45 (I2C Bus) Multiplexing: pay attention about the same types of sensors on the port! -  see note below LED Indicators: 1x PWR, 1x BUS Housing: metal case Environment: Temperature operating: -45 ~ 90 °C Humidity operating: 0% ~ 100% (non condensed) Temperature storage: -20 ~ 60 °C Humidity storage: 5% ~ 90% (non condensed) Certificates: CE, RoHS Dimension: 79 x 50 x 24 mm (Length x Width x Height) Weight: 230 Grams (only device) package content: 1x ALL4432 Brightness sensor 1x connection cable Multiplexing - Note to the operation of several sensors on one sensor port Basically, it is for the ARM and MIPS-based systems possible, unlike to the ALL3000/4000 to operate more than one sensor on a physical port. Standard hardware requirement is that the sensors are equipped with 2 RJ45 connectors so that the sensor signal can be continued to the next sensor. The total cable length of 100 m does not increase thereby. So that the sensors can be uniquely identified by the devices, it is necessary that these sensors have different software-I2C chip addresses and IDs. Sensors with the same address and adjustable chip ID can be combined. For sensors without adjustable ID address only one type of sensor can be connected per port.

Compatible with ALL34xx/350x/4500/5000/3692 4-Port contact input in metal case with wall mount option  4Port contact input (isolated) result of open contacts is "1", closed contact is "0" - possible solutions: idle door contact with puls stretching NOT COMPATIBLE WITH ALL3000/ALL40000.

Compatible with ALL3000/ALL34xx/3500/400x/4500/5000 volt meter in metal case housing with wall mount/desktop option detect when power fit or not 4-phase, for AC voltage 220...240V isolated over relay connections: 1x RJ45 INPUT / 1x RJ45 OUTPUT

Highlights:   new compact aluminum desktop- / wallmounting case I2C Bus for multiplexing use angle fixings for wall mounting   Measure, control and regulate automatically and independently ALLNET for years been pursuing the concept of intelligent control of processes in building over network and Internet. Intelligent building not only offers comfort, but actively promotes the reduction of energy costs. Centrally managed and via network / internet accessible the ALLNET Home Automation products allow intelligent building automation regardless of time and location. The ALL4452 PIR Movement detector has a max. detection angle of 92° and a max range of 8 meters. Movement detection Sensor in desktop-/ wallmounting case max. detection angle of 92°, max. range of 8 meters Aluminum housing with bracket for wall mounting Multiple multiplexing = multiple modules on one line Interfaces: 2x RJ45 Technical Details: Item Specification Sensor type   PIR movement detection   measuring range: max. detection angle of 92°, max. range of 8 meters Chip PCF8574 Interfaces: 2x RJ45 (I2C Bus) Multiplexing:   dial wheel for ID (8), see note below   LED Indicators: 1x PWR, 1x BUS, 1x Detetct Housing: metal case Environment: Temperature operating: -45 ~ 90 °C Humidity operating: 0% ~ 100% (non condensed) Temperature storage: -20 ~ 60 °C Humidity storage: 5% ~ 90% (non condensed) Certificates: CE, RoHS Dimension: 79 x 50 x 24 mm (Length x Width x Height) Weight: 230 Grams (only device) package content: 1x ALL4452 PIR Movement detection sensor 1x connection cable   Multiplexing - Note to the operation of several sensors on one sensor port Basically, it is for the ARM and MIPS-based systems possible, unlike to the ALL3000/4000 to operate more thanone sensor on a physical port. Standard hardware requirement is that the sensors are equipped with 2 RJ45 connectors so that the sensor signal can be continued to the next sensor. The total cable length of 100 m does not increase thereby. So that the sensors can be uniquely identified by the devices, it is necessary that these sensors have different software-I2C chip addresses and IDs. Sensors with the same address and adjustable chip ID can be combined. For sensors without adjustable ID address only one type of sensor can be connected per port.

Hightlights: new compact aluminium desktop- / wall mounting case I2C Bus for multiplexing use either in black or white available angle fixings for wall mounting Measure, control and regulate automatically and independently ALLNET for years been pursuing the concept of intelligent control of processes in building over network and Internet. Intelligent building not only offers comfort, but actively promotes the reduction of energy costs. Centrally managed and via network / internet accessible the ALLNET Home Automation products allow intelligent building automation regardless of time and location. The ALL4454 smoke detector/ sensor can also be used for detection of gases. Smoke detector/ Gas sensor in desktop-/ wallmounting case reports smoke and gas Aluminum housing with bracket for wall mounting Multiple multiplexing = multiple modules on one line Interfaces: 2x RJ45 (not compatible with ALL3000/400x) Technical Details: Item Specification Sensor type Smoke-/ Gas detector measuring range: 0 to 100 Chip ADS1100A3 Interfaces: 2x RJ45 (I2C Bus) Multiplexing: pay attention about the same types of sensors on the port! -  see note below LED Indicators: 1x PWR, 1x BUS Housing: metal case Environment: Temperature operating: -45 ~ 90 °C Humidity operating: 0% ~ 100% (non condensed) Temperature storage: -20 ~ 60 °C Humidity storage: 5% ~ 90% (non condensed) Certificates: CE, RoHS Dimension: 79 x 50 x 24 mm (Length x Width x Height) Weight: 230 Grams (only device) package content: 1x ALL4454 smoke detector / Gas sensor 1x connection cable Multiplexing - Note to the operation of several sensors on one sensor port Basically, it is for the ARM and MIPS-based systems possible, unlike to the ALL3000/4000 to operate more than one sensor on a physical port. Standard hardware requirement is that the sensors are equipped with 2 RJ45 connectors so that the sensor signal can be continued to the next sensor. The total cable length of 100 m does not increase thereby. So that the sensors can be uniquely identified by the devices, it is necessary that these sensors have different software-I2C chip addresses and IDs. Sensors with the same address and adjustable chip ID can be combined. For sensors without adjustable ID address only one type of sensor can be connected per port.

  Highlights:   new compact aluminum desktop- / wall mounting case I2C Bus for multiplexing use either in black or white available angle fixings for wall mounting       Measure, control and regulate automatically and independently   ALLNET for years been pursuing the concept of intelligent control of processes in building over network and Internet. Intelligent building not only offers comfort, but actively promotes the reduction of energy costs.   Centrally managed and via network / internet accessible the ALLNET Home Automation products allow intelligent building automation regardless of time and location.   The ALL4454 smoke detector/ sensor can also be used for detection of gases.     Smoke detector/ Gas sensor in desktop-/ wall mounting case   reports of smoke and gas Aluminum housing with bracket for wall mounting Multiple multiplexing = multiple modules on one line Interfaces: 2x RJ45 (not compatible with ALL3000/400x)   Multiplexing - Note to the operation of several sensors on one sensor port   Basically, it is for the ARM and MIPS-based systems possible, unlike to the ALL3000/4000 to operate more than one sensor on a physical port.   Standard hardware requirement is that the sensors are equipped with 2 RJ45 connectors so that the sensor signal can be continued to the next sensor. The total cable length of 100 m does not increase thereby.   So that the sensors can be uniquely identified by the devices, it is necessary that these sensors have different software-I2C chip addresses and IDs. Sensors with the same address and adjustable chip ID can be combined. For sensors without adjustable ID address only one type of sensor can be connected per port.     Technical Details:   Item Specification Sensor type Smoke-/ Gas detector measuring range: 0 to 100 Chip ADS1100A3 Interfaces: 2x RJ45 (I2C Bus) Multiplexing: pay attention about the same types of sensors on the port! -  see note below LED Indicators: 1x PWR, 1x BUS Housing: metal case Environment: Temperature operating: -45 ~ 90 °C Humidity operating: 0% ~ 100% (non-condensed) Temperature storage: -20 ~ 60 °C Humidity storage: 5% ~ 90% (non-condensed) Certificates: CE, RoHS Dimension: 79 x 50 x 24 mm (Length x Width x Height) Weight: 230 Grams (only device) package content: 1x ALL4454 smoke detector / Gas sensor 1x connection cable

compatible with ALL3000/3418v2/3500/400x/4500/5000detect when power fit or notisolated by relaismetal case with wallmount optionconnection: 1x RJ45 INPUT, 1x RJ45 OUTPUT, 2pin screw connection

Highlights:   compatible with ALL3418v2/3419/35xx/4500/5000 Carbon dioxide sensor "CO2 sensor" displays the values in ppm. Aluminium housing with bracket for wall mounting CO2 measuring range 0-40000ppm Measurement accuracy ± (30 ppm + 3% MV) / (25 °C, 400 - 10'000 ppm) Connections: 1x RJ45 input / 1x RJ45 output (no longer compatible with ALL3000/400x & ALL4504/4404 8 Port Multiplexer) ALL4471 - Sensor Module for HVAC and Indoor Air Quality Applications ALLNET Technology for IR detection enables highly accurate carbon dioxide measurement at a competitive price. Along with the NDIR measurement technology for CO2 detection. Thanks to the dual-channel principle for the measurement of carbon dioxide concentration, the sensor compensates for long-term drifts automatically by design. The very small module height allows easy integration into different applications. Carbon dioxide is a key indicator of indoor air quality. Thanks to new energy standards and better insulation, houses have be-come increasingly energy efficient, but the air quality can deteriorate rapidly. Active ventilation is needed to maintain a comfortable and healthy indoor environment, and to improve the well-being and productivity of the inhabitants. ALLNET´s ALL4471 offers accurate and stable CO2. This enables customers to develop new solutions that increase energy efficiency and simultaneously support well-being.   Technical Details: CO2 Sensor Specifications CO2 measurement range 0 - 40'000 ppm Accuracy ± (30 ppm + 3% MV) (25 °C, 400 - 10'000 ppm) Repeatability 10 ppm Temperature stability 2.5 ppm / °C (0-50 °C) Response time (t63) 20 s Humidity Sensor Specifications Relative humidity measurement range 0 - 100 % RH Typ accuracy ±3% RH (0-100% RH) Repeatability 0.1% RH Response time (t63) 8 s Electrical Specifications Supply voltage 3.3 - 5.5 V Average current  @ 2s measurement rate 19 mA Max. current 75 mA

Highlights: compatible with ALL34xx/35xx/4500/5000 Particulate matter sensor shows the values in µg/m3, particles per cubic cm  Aluminium housing with bracket for wall mounting Fine dust measuring range 1 to 1000 µg/m3 Measurement accuracy ±10 µg/m3 @ 0 to 100 µg/m3 / ±10 % @ 100 to 1000 µg/m3 Connections: 1x RJ45 input / 1x RJ45 output (no longer compatible with ALL3000/400x & ALL4504/4404 8 Port Multiplexer) Particulate Matter Sensor ALL4472 For HVAC and Air Quality Applications With this new particulate matter sensor, ALLNET expands its range of environmental sensing solutions and opens up a new dimension in indoor and outdoor air quality applications. The ALL4472 particulate matter (PM) sensor represents a new technological breakthrough in optical PM sensors. Its measurement principle is based on laser scattering and makes use of ALLNET's innovative contamination-resistance technology. This technology, together with high-quality and long-lasting components, enables accurate measurements from the device's first operation and throughout its lifetime of more than eight years. PM2.5 and PM10 refer to particulate matter with particle diameter up to 2.5 microns and 10 microns, respectively, and are among the most dangerous air pollutants. Due to their small size, PM2.5 particles can travel deep into the human lung and cause a variety of health issues; for instance, by triggering asthma attacks or contributing to cardiovascular disease. The ALL4472 will enable the implementation of innovative air quality monitoring devices that prevent air pollution damage.  Technical Details: Particulate Matter Sensor Specifications Mass concentration accuracy1 ±10 μg/m3 @ 0 to 100 μg/m3 ±10 % @ 100 to 1000 μg/m3 Mass concentration range 1 to 1000 μg/m3 Mass concentration resolution 1 μg/m3 Particle detection size range2 Mass concentration:   PM1.0, PM2.5, PM4 and PM10 Number concentration:  PM0.5, PM1.0, PM2.5, PM4 and PM10 Lower limit of detection 0.3 μm Minimum sampling interval 1 sec (continuous mode) Lifetime > 8 years operating continuously 24h/day Dimensions 40.6 x 40.6 x 12.2 mm3 Operating temperature range -10 to +60 °C Storage temperature range -40 to +70 °C Electrical Specifications Interface UART, I2C, RJ45 "ALLNET" Supply voltage 4.5 – 5.5 V Average supply current @ 1 Hz measurement rate < 60 mA 1 Specified for PM2.5 at 25 °C using potassium chloride salt particles and the TSI DustTrakTM DRX Aerosol Monitor 8533 as a reference. 2 PMx defines particles with a size smaller than "x" micrometers (e.g., PM2.5 = particles smaller than 2.5 μm).

compatible with ALL3418v2/3419/3500/4500/5000 1-port contact input module in housing Connection of one (potential-free) contact Open contacts are evaluated as "1", closed contacts as "0" - ideal e.g. for closed-circuit current loops (door contacts) For operation with the control units, a suitable patch cable of the desired length is required. ATTENTION NOT COMPATIBLE WITH OLD SERIES ALL3000/4000

Leakage Sensor for 3418v2/34xx/35xx/4500/5000 - Detects if leading conductive liquid is present on the floor - In the display / central unit, the display is shown in % percentage = Example: Ca. 95~100% floaters are in the water. 50% display = There is still some conductive liquid present on the floor. From 40% the threshold is pre-configured from green to red. - Connections: 2x RJ45 I2C at the sensor housing - Including 2m cable length to the floaters that register the conductivity of the liquid on the floor Example view in WebGUI: Sensor information: Installation example:
